      EUROSTOP BUTTERFLY VALVE WATER TREATMENT VERSION

      heavy_duty

      Range:

      DN 150–2000
      PN 10-16-25–40


      Double eccentric resilient seated butterfly valve with
      bi-directional sealing , double flange long pattern series 14.

      High corrosion resistance materials selected for sewage
      and water treatment plant applications.

      The automatic gasket design allows a perfect leak proof
      seal in the 2 ways of flow, while the double eccentric disc
      design reduces torques and gasket drag, minimizing the
      frictions and reducing the gasket wear and tear.

      Applications: Waste Industry

      Materials

      • Body and valve disc: ductile iron GJS500-7 EN 1563
      • Seat: stainless steel AISI316L
      • Shafts: in stainless steel DUPLEX
      • Valve automatic gasket: NBR
      • Screws A4
      • Retaining ring stainless steel AISI 316
      • Bush: Bronze Aluminium EN 1982 CuAl11Ni4F
      • Primary and secondary shaft tightness: bronze bearings with double internal and external NBR O-rings sealing

      Features

      • Performance and design according to EN1074-1 and 2,  EN593
      • Face to Face dimension according to EN 558 e ISO 5752-14
      • Flanges drilling in according to EN 1092-2 ISO 7005-2; ANSI150
      • Double eccentric offset valve
      • NBR automatic gasket design
      • Bi-directional tight closure
      • Hydraulic test in  accordance with the prescriptions EN 1074 1 and 2, ISO 5208 and EN 12266 leak Rate A
      • Marking  according EN 19

      Corrosion protection

      • Body and valve disc epoxy powder coated in every part in accordance with EN14901 layer thickness min. 300 μm

      Gearboxes and actuators

      • AUMA Gearboxes Enclosure IP68-8 according to EN60529
      • Standard Actuator S2-15 min, 400 V -3 – 50Hz, IP68.8, KS protection and heater 230 V
